ZUBER rock trimmer MP 10 (waiting time!)

$6,595.00
Item number
ROCK 1001678

Universal device for easy splitting of all rock types, as well as to expose fossils.
Fast and effortless operation, easy to use.
Trimming and reset the upper bits with only one handle.
Height adjustment with nut.
High pressure force of 10 tons, using specially enhanced hydraulic for this larger device.

Passage 150 x 330 mm. Hydraulic stroke max. 30mm

Rugged, stable construction. Bilateral guards.

Weight only 45 kg

Specifications:
Inside width: 330 mm
Cutting height max. 150 mm
Weight: 45 kg
Max Force: 10 tons (100 kN)
Hydraulic working max: 30 mm.
Spindle: 90 mm
Bit 90: 1 pair each 35 mm and 60 mm high
Hydraulic oil to DIN 51524 T2 HPL (30cST/50 °)
Operating temperature: 0 - 40 ° C
Operating pressure, max. 520 bar (52 MPa)

Picture shows MP-5 for comparison purpose. MP-5 unit in NOT included in this offer.



More Information
shipment-weight, NOT netto weight (kg) 100.000000
